What is coffee beans packing machine?
AF-VT52 coffee beans packing machine is a complete solution to pack coffee beans into the bags; this machine can form the bags, auto-feed the coffee beans, Auto weigh the coffee beans, Auto fill into the bags, and auto seal the bags. The goodcoffee beans packaging machine should be fully automatic, easy to use and maintain, reliable working, high filling accuracy, beautiful sealing, quiet running, multi-functions, etc.
AFPAK’s coffee beans packing machine can meet all your requirement. this machine not only produces coffee beans but also produces solid materials like any beans, Fried food, Snacks, etc.. Is the right choice for all small and medium enterprises
There are many optional functions for you to choose from: Sticky function of degas valve, date printing function, different cutting shapes, etc.
Dettagli della macchina
This coffee beans packing machine is to produce the four sides seal bags like the following:
1. Vertical coffee beans packing machine introduce:
Technical characteristics
- PLC control with stable, reliable biaxial high accuracy output and color touch screen, bag-making, measuring, filling, printing, cutting, finished in one operation.
- Separate circuit boxes for pneumatic control and power control. Noise is low, and the circuit is more stable.
- Servo control, high precision orientation, size more nicety.
- External film releasing mechanism: simpler and easier installation of packing film.
- Adjustment of bag deviation just needed to control the touch screen. The operation is very simple.
- Close down type mechanism, defending powder into the inside of the machine.
Technical parameters of coffee beans packing machine:
| Dimensione della borsa | Font width: 70-180 mmSide width: 40-100 mmSealing width: 5-10 mmLength: 100-350 mm |
| Max width of roll film | 520mm |
| Velocità di imballaggio | 20-30bags/min |
| Measuring range | 3000ml(MAX) |
| Consumo d'aria | 0.65Mpa |
| Gas consumption | 0.4m³/min |
| Power voltage | 220VAC/50HZ |
| Energia | 3.5Kw |
| Dimensione | L 1300* W 1130* H 1900mm |
| Deadweight of machine | 700KG |
2. Coffee beans Weigher
Special Features：
- Special design to mount on the top of VFFS bagger into combine machine, save cost and space;
- Servo motor duck mouth timing hopper, collect products into one filling point to reach high speed;
- HMI program can be changed according to customize requirement;
- Central weight and level sensor checking, double-check for all kinds of product features;
- AFC auto adjust linear vibration, make sure good accuracy;
- Initial program recipe easy for operator setting, and save recipes same as micron office with a different name;
- Piston up & down function to stop products collision, good for fragile products;
- Measure by weight or counting piece, both are available.
Technical parameters of coffee beans weigher
| Max. Single Dump Cap. (g) | 10-1500g |
| Weighing Accuracy | 0.5-2.0g |
| Max. Weighing Speed | 120bpm |
| Weigh Hopper Volume | 2500ml |
| Pannello di controllo | Touch screen |
| Options | Dimple Plate/Timing Hopper/Printer/Rotary Top Cone |
| Driving system | Step Rotor |
This machine is 10 heads design, we also have 6-20 heads for you to choose.
3. Z type Coffee beans feeding tunnel
| Convey speed | 3600mm |
| Energia | 750W |
| Convey measure | 4T/H(Rice) |
| Overall size | 3000(L)*650(W)*3750(H)mm |
4. Weigher loading frame
| Maximum Loading Weight | 2T-3T |
| Equipment Size | 1850mm*1850mm*1850mm |
| Net Weight | 350kg |
5. Output conveyor
| Convey speed | Speed can be changed(fast or slow depends on your choice); Average speed: 30m/min |
| Energia | 220V/40W/50HZ |
| Belt | Food grade polypropylene(PP) |
| Weight of machine | 100KG |
| Packaging size | 1600mm(L)*550mm(W)*1000mm(H) |
6. Recommend functions- degassing valve seal function
Configurations
AF-VT52 Coffee beans Packing Machine configurations
| Nome | Marca | Producing area | Remark |
| Touch-sensitive screen | WEINVIEW | Taiwan | |
| Programmer controlled system | SIMENS | Giappone | |
| Servomotore | Schneider | Francia | |
| Servo driver | Schneider | Francia | |
| Cylinder | SMC | Giappone | |
| Cylinder | SMC | Giappone | |
| Electromagnetic valve | Jinqi | Taiwan | |
| Relè intermedio | weidmuller | Germania | |
| Photoelectric eye | BEDELI | Taiwan | |
| Energia | Schneider | Germania | |
| Solid state relay | Crydom | Messico | |
| Thermometer control | OMRON | Giappone |
Factory Tour
FAQ
1. What kind of the bags can this coffee bean packing machine produce
AFPAK: This machine can produce the four sides seal bags, which is a standable, Elegant design.
2. Can I use other shapes of the bags on coffee beans packaging machine
AFPAK: We don’t suggest you do this. Because if change the shapes, then you need to change the forming parts, which is very complicated.
3. Can I produce different sizes of the bags in one machine
AFPAK: Yes, You can. you can change the bag height when producing to load more filling materials. We don’t suggest changing the width of the bags, because you will need to change the forming parts. And VT52 machine is more complicated to change this part
4. Can I produce different products with this machine?
AFPAK: Sure, you can produce many different solid products with this machine, and no need to change the machine parts, only need to change the parameters in the machine control screen.
5. What do you need to know before ORDER this machine?
AFPAK: As this is a customized machine, so we need to know from you: the detailed bag size (L, W, H), what to fill, what’s the speed you want, what’s your factory size and power, etc.
6. How soon will I get my machine after Order?
AFPAK:Normally, machine produce needs 2 months. and shipping needs 2-8 weeks to your port. So if need the machine, please order in early time.
7. What’s the price of this machine?
AFPAK: The machine prices are different from your needs. so please contact our sales for more details.
8. Can I visit your factory?
AFPAK: Sincerely welcome all customers to visit our factory. We will always arrange pick-up and escort services.
